Drop-in counters

The new way of exposing



This new display mode responds to the need to position the product at the same height as the worktop. This combines excellent product visibility with the maximum ease of service and cleaning. Refrigerated, heated and non-refrigerated tops in a vast range of gastronorm and euronorm sizes, for confectioners, chocolate makers, delicatessens and bakeries.

Drop-in counters features



WELLS PLACED SIDE BY SIDE / WELLS INSTALLED IN-LINE

fan-refrigerated drop-in wells can be installed in-line to create the length desired, with no break in the display surface. wells are normally installed beneath the top; for flush-mounted installation, an optional steel surround is required.

DROP-IN COUNTERS

drop-in counters are available with all the refrigerated and heated drop- in wells in the range. worktops, in stainless steel or other materials, are optional. there is a choice of various materials including satined or gloss stainless steel, laminated wood in matching colour and real or imitation marble.

FAN-REFRIGERATED DROP-IN WELL WITH ADJUSTABLE TOP

well in aisi 304 stainless steel with injected polyurethane internal insulation. refrigeration system with thermostat valve and adjustable fan. adjustable-height stainless steel display plates. condensate drain in bottom. available dual function (hot-cold).

DROP-IN, FAN-REFRIGERATED WELL WITH FLUSH-MOUNTED TOP

well in aisi 304 stainless steel with injected polyurethane internal insulation. refrigeration system with thermostat valve and adjustable fan. stainless steel display plates flush with top. condensate drain in bottom. available dual function (hot-cold).

STATIC-REFRIGERATED WELL

well in aisi 304 stainless steel with injected polyurethane internal insulation. refrigeration by means of copper coil inside the well. condensate drain in bottom. can be fitted with set of gastronorm basins.

CONTACT FAN-REFRIGERATED WELL WITH FLUSH-MOUNTED TOP

well in stainless steel with injected polyurethane internal insulation. refrigeration by means of bottom-mounted copper coil. built in aisi 304 stainless steel, it has rounded corners and condensate drain in bottom.

CONTACT-REFRIGERATED WELL WITH STONE TOP

well in stainless steel with injected polyurethane internal insulation. refrigeration by means of bottom-mounted copper coil. built in aisi 304 stainless steel, it has rounded corners and condensate drain in bottom. the display top may be in stone, granite, composite or extra-thick steel. low temperature conduction depends on the top material.

HEATED BAIN-MARIE WELL WITH BASINS

the bain-marie heated well is built in press-formed aisi 304 stainless steel with top edge for fitting into the top. it is heated by electric elements on the outside of the well bottom and has a bottom drain. fitted with gastronorm basin compositions or perforated stainless steel display surfaces.

DRY-HEATED TOP IN BLACK GLASS/STEEL

the dry-heated top has insulated stainless steel well, anodised aluminium edging and black glass or aisi 304 stainless steel display surface. contact electric heating elements.
